C6644HD Digital Audio Processor
- Professional 16-in / 16-out digital audio processor
- Built-in 32-bit floating-point DSP processor
- 24-bit / 48kHz high-quality audio conversion
- Full-function matrix mixing support
- Supports AFC, AEC, ANS, AUTOMIXER, EQ, GATE, and AGC
- High-precision input sensitivity adjustment
- Supports 48V phantom power
- USB interface supports recording and broadcasting
- Supports Dante network audio transmission
Product Description
Specifications
Product Description
The C6644HD is a professional 16-input / 16-output digital audio processor designed for conference rooms, theatres, concert halls, sports venues, churches, theme parks, command centers, and large sound reinforcement systems. It provides flexible matrix mixing and advanced audio processing for clear, stable, and controlled sound performance.
Built with 24-bit / 48kHz audio conversion, a 32-bit floating-point DSP processor, and professional audio algorithms, the C6644HD supports feedback cancellation, echo cancellation, noise suppression, automatic mixing, EQ, gate, and gain control. It also supports Dante network audio transmission, making it suitable for modern networked conference and professional audio systems.
Specifications
| Specification | Details |
|---|---|
| Model | C6644HD |
| Type | Digital Audio Processor |
| Input / Output | 16 Inputs / 16 Outputs |
| Audio Conversion | 24-bit / 48kHz |
| DSP Processor | 32-bit Floating Point DSP |
| Phantom Power | 48V |
| Frequency Response | 20Hz–20kHz |
| Power Supply | AC220V / 50Hz |
