CX408P 4 Input & 8 Output Professional Audio Processor
- Professional 4-input / 8-output audio processor
- Supports 4 analog inputs and 8 analog outputs
- Each input supports AES3 signal switching
- Optional 4×4 Dante network audio support
- High-performance DSP processing with 24-bit / 96kHz sampling
- Input 15-band PEQ and output 10-band PEQ
- Supports HPF, LPF, all-pass, band-pass, band-stop, and notch filters
- FIR linear phase processing with 512-tap FIR settings
- USB, TCP/IP, and RS232 control support
Product Description
Specifications
Product Description
The CX408P is a professional 4-input / 8-output audio processor designed for stage sound, bars, venues, professional speaker management, and high-end sound reinforcement systems. It supports multiple input signal types including analog, AES3, and optional Dante network audio, making it flexible for modern audio installations.
Built with a high-performance ADI SHARC DSP processor, 24-bit / 96kHz AD/DA conversion, Dynamic EQ, and FIR linear phase processing, the CX408P delivers precise audio control and wide dynamic performance. It can be managed through USB, TCP/IP, and RS232, with Mconsole PC software for easy system setup and multi-device control.
Specifications
| Specification | Details |
|---|---|
| Model | CX408P |
| Type | 4 Input & 8 Output Audio Processor |
| Input Channels | 4 Balanced Inputs |
| Output Channels | 8 Balanced Outputs |
| DSP Processor | ADI SHARC 21489, 450MHz |
| AD/DA Conversion | 24-bit / 96kHz |
| System Delay | 2.1ms |
| Dante Audio | 4×4 Optional |
