CX1000 Series Dual Channel Class D Digital Amplifier
- Professional dual-channel Class-D digital amplifier series
- Available in multiple power models: CX1500 / CX2000 / CX2500 / CX3000 / CX3500 / CX4000
- Supports mono, stereo, and BTL bridge output modes
- Each channel has independent volume control
- XLR and 6.35mm phone jack audio input support
- LED indicators for power, clip, signal, DC, and temperature status
- Short-circuit, DC output, and high-temperature protection
- Power shock protection to protect audio equipment and power grid
- Suitable for stages, halls, venues, entertainment, and professional audio systems
The CX1000 Series is a professional dual-channel Class-D digital amplifier series designed for high-power sound reinforcement applications. It includes models such as CX1500, CX2000, CX2500, CX3000, CX3500, and CX4000, offering different power ranges to match various venue and speaker system requirements. With its dual-channel stereo design and modern appearance, it is suitable for stages, halls, entertainment venues, auditoriums, conference spaces, and professional audio installations.
This amplifier series supports multiple working modes including mono, stereo, and BTL bridge mode, giving users flexible system configuration options. Each channel has independent volume control and LED indicators for working status monitoring. With XLR and 6.35mm audio inputs, short-circuit protection, DC protection, high-temperature protection, and power shock protection, the CX1000 Series provides stable, safe, and reliable performance for professional sound systems.
| Specification | Details |
|---|---|
| Model | CX1000 Series |
| Type | Dual Channel Class-D Digital Amplifier |
| Model Options | CX1500 / CX2000 / CX2500 / CX3000 / CX3500 / CX4000 |
| Rated Output / Channel at 8Ω | 230W–1000W |
| Rated Output / Channel at 4Ω | 350W–1500W |
| Bridge Output at 8Ω | 700W–3000W |
| Frequency Response | 20Hz–20kHz ±3dB |
| Power Supply | AC220V / 50Hz |
