CX-MP9306U 60W Ultra-thin Digital Mixer Amplifier
- Professional 60W ultra-thin digital mixer amplifier
- Supports Bluetooth, USB, and line working modes
- Wireless Bluetooth playback with remote control support
- Includes 2 microphone inputs and 2 line inputs
- Supports 100V priority input and EMC input
- Provides 100V speaker output and auxiliary output
- Priority function: 100V input > MIC1 > other inputs
- Signal, clip, and protection LED indicators
- Built-in short-circuit, overload, high-temperature protection, and temperature-controlled fan
The CX-MP9306U is a compact 60W ultra-thin digital mixer amplifier designed for public address, background music, paging, and small commercial sound reinforcement systems. It is suitable for classrooms, offices, retail stores, cafés, restaurants, meeting rooms, reception areas, small halls, and commercial buildings. With its slim 1U-style body and integrated mixer-amplifier design, it provides a space-saving audio solution for fixed installations where simple operation and reliable daily performance are required.
This amplifier supports Bluetooth, USB, and line working modes, allowing easy music playback from wireless and wired audio sources. It includes 2 microphone inputs, 2 line inputs, 100V priority input, EMC input, 100V speaker output, and auxiliary output for flexible PA system connection. With MIC1 priority, volume controls for microphones and line inputs, bass/treble adjustment, signal/clip/protection indicators, temperature-controlled fan, and protection against short circuit, overload, and high temperature, the CX-MP9306U is a practical choice for small PA and business audio installations.
| Specification | Details |
|---|---|
| Model | CX-MP9306U |
| Type | Ultra-thin Digital Mixer Amplifier |
| Rated Power | 60W |
| Speaker Output | 100V |
| Working Modes | Bluetooth / USB / Line |
| Inputs | 2 MIC / 2 Line / EMC / 100V Priority |
| Frequency Response | 80Hz–15kHz ±3dB |
| Power Supply | AC 180–250V / 50–60Hz |
