CX-MAG505 System Host
Features
● Wall-mounted Touch Control Panel.
● Covered with white or black colour glass.
● Adjust volume, select music, mute audio and push local audio to the public address system.
● One matrix mixer can support 5 units of wall controllers.
Product Description
Specifications
Product Description
CX-MAG505 audio router is designed to support 5 audio outputs, with the ability of selecting one of four audio sources for each output independently. It’s a stereo gadget with an RS232 interface and wall-mounted touchpads for controlling the primary functions. The MAG505 features an integrated USB player as well as Bluetooth and FM receivers. Priority input for emergency audio; external mute contact in an emergency.
Specifications
| Model | CX-MAG505 |
| Power Supply | 100-240VAC, 50/60Hz |
| Fuse | T1AL |
| Media Player | USB/Bluetooth |
| Bluetooth Version | V5.0 |
| MIC Input Sensitivity | -41dBV |
| Line Input Sensitivity | -12.5dBV |
| Call Station Input Sensitivity | +4dBV |
| EMC Input
SN Ratio to MIC Input SN Ratio to Line Input |
Sensitivity -10dBV
65dB 73dB |
| Outputs | 5 stereo zones |
| Output Impedance | 600 ohm |
| THD+N | ＜0.1%@1KHz |
| Phantom Power | +24V DC |
| Frequency Response | ±3dB 20Hz-20kHz |
| Dimensions | 483×177×44mm |
| Weight | 1.76kg |
