CX-MAG2588 250 Zones Remote Paging Station
Features
● 7-inch true color touch color, high-grade aluminum alloy industrial drawing panel design.
● Desktop design.
● High-fidelity and hand-held dynamic microphone design.
● Possess multi-level level indication, and the sound pressure is more intuitive.
● Convenience for quick paging in emergencies with manual shortcut keys.
● Graphic user-friendly design, more intuitive display.
● Embedded real-time system platform, high-performance ARM processor.
● Built-in bell sound.
● Paging function of the host partition.
● User password and privilege management.
● With automatic intelligent microphone-off function, you can see turn off paging time delay by the speaker.
● Manually turn on and turn off the paging microphone power supply.
● With intelligent screen protection function, you can set the color display screen protection delay time.
Input sensitivity | Mic: 10mV(±1mV), unbalance
Line: 300mV(±50mV), unbalance |
Audio signal output | Line output:1V(±0.1V) |
Chime output:0.8V-1V | |
Chime output type | CHIME1: note1-3-5-i |
CHIME2: notei-5-3-1 | |
CHIME3: note i-5-i-5 | |
Frequency response | Mic: 150Hz-10kHz(±3dB); Line: 20Hz-20kHz(±3dB) |
Distortion | MIC: ≤1.5% |
Line: ≤0.1% | |
Signal to noise ratio | Mic input ≧60dB
Line input≧70dB |
Protection | AC fuseF1L |
Power | AC 220-240V/50-60Hz/5W |
Device size(mm) | (L×W×H)270×180×120 |
Gross weight | 3.5kg |
Net weight | 2.2kg |
