CX-MAG1116 10 Zones Intelligent Public Address Center
Features
● 5″ color touch screen for friendly use
● 10 zones audio outputs
● Audio sources: Mic input, USB, SD
● With built-in Fireman Mic for emergency use
● Editable voice recording function for voice evacuation
● Support 2 remote paging stations
● Support AB speaker ouputs (BGM & emergency broadcast)
● 10 channel fire alarm inputs and 1 short circuit output
● Weekly timer function: 5 programs, each 200 points
● Support monitoring function to each zone
● 4 AC power output for external equipment
● DC24V power supply could be customed (MAG1116D)
Product Description
Specifications
Product Description
CX-MAG1116 is a robust intelligent PA system centre. It is a 10-zone PA system solution. The system has standard PA capabilities like background music, programmed audio, remote paging, and fire alarms.
It accepts 5 audio inputs and 10 zone outputs. The audio sources include AUX, USB, SD, and tuner ports. It supports AB line speaker outputs for background music and emergency broadcasts.
The technology allows for remote paging and programmed timers to simplify daily operations.
The system is reliable and robust thanks to the use of an industrial PCB and a competent Connex architecture. This is a cost-effective and reliable PA solution for small to medium venues, such as schools, supermarkets, and factories.
Specifications
| No. | Item | Indicator requirement | Unit | |
| 1 | Channel B output
At 1V/1KHZ sine wave |
Microphone input sensitivity | 2–3.5 | mV |
| Wireless microphone input sensitivity | 200–350 | mV | ||
| Remote paging input sensitivity (voltage at pin No.8 and No.9) | 1000±100 | mV | ||
| Line recording input sensitivity | 200–350 | mV | ||
| Microphone recording input sensitivity | 2–3.5 | mV | ||
| 2 | Channel A output
At 1V/1KHZ sine wave |
MP3 input sensitivity | 200–350 | mV |
| Line recording input sensitivity | 200–350 | mV | ||
| Microphone recording input sensitivity | 2–3.5 | mV | ||
| 3 | Maximum noise | Channel A/B (When channel B is switched to wireless microphone) | ≤0.5 | mV |
| When channel B is switched to local microphone input | ≤1 | mV | ||
| Monitoring | ≤1.5 | mV | ||
| 4 | Degree of distortion
(Output of 1KHZ 1V) |
Channel A/B (Input of line) | ≤0.3 | % |
| Channel B (Input of local microphone) | ≤0.5 | % | ||
| 5 | Frequency response (±3dB) | Microphone input frequency response | 50—20K | HZ |
| Remote paging microphone input frequency response | 50—20K | HZ | ||
| Wireless microphone input frequency response | 100—20K | HZ | ||
| MP3 output frequency response | 200—20K | HZ | ||
| Line recording input frequency response (output of channel A) | 350—20K | HZ | ||
| Line recording input frequency response (output of channel B) | 100—10K | HZ | ||
| 6 | Monitoring | (220V power supply/1KHZ, ≤1% degree of distortion) | 6-7.5 | V |
| (+24V power supply/1KHZ, ≤1% degree of distortion) | 5-6 | V | ||
| 7 | Protection | 1.AC220V/ 1A; 2.DC+24V/2A (Only for MAG1116D) | ||
| 8 | Dielectric strength test | Between poles of power supply and input/output terminal | 4200 | VDC |
| Between poles of power supply and metal shell | 2200 | VDC | ||
| 9 | Net weight | 8kg | ||
| 10 | Gross weight | 9.5kg | ||
| 11 | Machine Dimension (L×W×H) | 483×350×88mm | ||
| 12 | Package Dimension (L×W×H) | 555×455×185mm | ||
